| Category | Hi-Temp Medium Duty | Item NO. | H50175/U2-H505-14U2 |
| Wheel Diameter | 5"(125mm) | Mounting Type | Bolt Hole Swivel |
| Tread Material | Hi-Temperature | Dynamic Load | 120kg |
| Wheel Width | 30mm | Mounting Height | 156mm |
| Surface Treatment | Zinc Coating | Standard Bolt Hole | φ12.7mm |
| Bracket Thickness | 2.5mm | Bracket Width | 41mm |
| Bearing | Sleeve | Core Material | / |
| Tread Color | Black | Frame Material | Cold-Rolled Plate |
| Applicable Temperature | 268℃ | Tread Hardness | 67D |
Product Details
